CAST STEEL GATE VALVE API600 - CLASS 1500
Product standards & features
| Standards | Detail |
| Design | API 600, ASME B16.34 |
| Face to Face | ANSI B16.10 |
| Flange Ends | ANSI B16.5 RF |
| Inspecion & Testing | API 598 |
| Marking | MSS SP-25 |
| Application | Coal industry, Oil&Gas, Power plant, Chemical industry, Waste water, water treatment industry |
| Features | Full bore / Standard bore design OS&Y, outside screw and yoke Rising stem and non-rising hand wheel BB, bolted bonnet Flexible wedge, fully guided Choice of solid or split wedge Renewable seat rings Forged T-head stem By pass on request Available with gear operator |
| Class | 150LB – 2500LB |
| Size | 2″ – 48″ (DN50~1200mm) |
| Material | Carbon steel (WCB) Stainless steel 304 (CF8) Stainless steel 316 (CF8M) |
| Application Medium | water, waste water, oil, gas, slurry, pulp |
| Application Temperature | -29℃~+425℃ (higher temperature is available upon request) |
PRODUCT DETAILS
CAST STEEL GATE VALVE API600 - CLASS 1500
Charlies Valve’s Cast Steel Gate Valve is built to the stringent API 600 standard, offering proven isolation performance for pressure classes ranging from 150 to 2500. Its robust cast steel construction provides exceptional durability for demanding petroleum and process applications. This valve ensures reliable shut-off and an unobstructed straight-through flow path, making it the industry-standard solution for critical operational integrity and long-term service.
Product Downloads
Your direct source for Charlies Valve technical specifications and product catalogs.
