CAST STEEL SWING CHECK VALVE API600 CLASS 2500
Product standards & features
| Standards | Detail |
| Design | API 600, ASME b16.34 , BS 1868 |
| Face to Face | ANSI B16.10 |
| Flange Ends | ANSI B16.5 / B16.47 |
| Inspecion & Testing | API 598 |
| Marking | MSS SP-25 |
| Application | Coal industry, Oil&Gas, Power plant, Chemical industry, Waste water, water treatment industry |
| Features | Standard swing type disc Standard renewable seat BC, bolted cover Non-penetrate disc shaft Horizontal or vertical service Flanged or butt-welding ends |
| Class | 150LB – 2500LB |
| Size | 2″ – 30″ (DN50~750mm) |
| Material | Carbon steel (WCB / LCB) Alloy steel (WC6 / WC9) Stainless steel (CF8 / CF8M) |
| Application Medium | water, sea water, oil, gas, corrosive liquids |
| Application Temperature | -29℃~+425℃ (higher temperature is available upon request) |
PRODUCT DETAILS
CAST STEEL SWING CHECK VALVE API600 CLASS 2500
Charlies Valve’s Cast Steel Swing Check Valve is built to stringent industry standards like API 6D, offering dependable backflow prevention across pressure classes from 150 to 2500. Its robust cast steel construction provides superior durability for demanding petroleum and process applications. This self-actuating valve automatically protects critical equipment from pressure surges and flow reversal, making it the industry-standard solution for ensuring system integrity.
Product Downloads
Your direct source for Charlies Valve technical specifications and product catalogs.
