FORGED STEEL GLOBE VALVE API602 CLASS 800
Product standards & features
| Standards | Detail |
| Design | API 602, ASME B16.34 |
| Face to Face | ASME B16.10 |
| Threaded Ends: | |
| NPT | ASME B1.20.1 |
| Socket Weld | ASME B16.11 |
| Butt Weld | ASME B16.25 |
| Inspecion & Testing | API 598 |
| Marking | MSS SP-25 |
| Application | Coal industry, Oil&Gas, Power plant, Chemical industry, Waste water, water treatment industry |
| Features | Straight-body design for smooth flow OS&Y type with exposed stem for easy monitoring Bolted bonnet with integrated yoke for added strength Rising stem with handwheel operation Loose disc design – plug or ball option Replaceable seat ring for easy maintenance Impact handwheel standard from 10” up Optimized for horizontal installation Flanged or butt-welded ends available Optional gearbox for effortless control |
| Class | 800LB – 2500LB |
| Size | 1/2” – 2” (DN 15mm ~ 50mm) |
| Material | Carbon steel (A105 / LF2) Alloy steel (A182 F11 / F22 / F51) Stainless steel (A182 F304 / F316 / F321) |
| Application Medium | water, waste water, oil, gas, slurry, pulp |
| Application Temperature | -29℃~+425℃ (higher temperature is available upon request) |
PRODUCT DETAILS
FORGED STEEL GLOBE VALVE API602 CLASS 800
Charlies Valve’s Forged Steel Globe Valve is engineered to the rigorous API 602 standard, delivering superior flow regulation for high-pressure services up to Class 800. Its high-integrity forged steel body ensures maximum strength for severe conditions, while the efficient globe design provides precise throttling control and dependable shut-off. This valve is the definitive choice for critical applications requiring exacting flow modulation and operational safety.
Product Downloads
Your direct source for Charlies Valve technical specifications and product catalogs.
