SLEEVE TYPE SOFT SEAL PLUG VALVE
Product standards & features
| Standards | Detail |
| Design | API599, AP16D |
| Face to Face | ANSI B16.10 |
| Flange Ends | ANSI B16.5 RF |
| Inspecion & Testing | API 598 |
| Marking | MSS SP-25 |
| Application | Natural gas industry, Oil production field, Chemical industry |
| Features | Compact design with strong sealing, smooth performance, and clean appearance 360° metal edge protects and secures the sleeve while sealing around it Cavity-free body prevents medium buildup Rotating plug uses metal edge for self-cleaning in sticky or sandy conditions Bi-directional flow simplifies installation and operation Materials and flange sizes can be tailored to fit actual service needs Supports gear operator for easier handling |
| Class | 150LB – 900LB |
| Size | 1/2” – 14″ (DN15~350mm) |
| Material | Carbon steel (WCB) Stainless steel 304 (CF8) Stainless steel 316 (CF8M) |
| Application Medium | water, waste water, oil, gas, steam, corrosive mediums |
| Application Temperature | -29℃~+180℃ |
PRODUCT DETAILS
SLEEVE TYPE SOFT SEAL PLUG VALVE
Charlies Valve’s Sleeve Type Soft Seal Plug Valve offers exceptional, maintenance-free performance for corrosive and high-purity applications. Its innovative design features a full PTFE sleeve that creates a large, circumferential sealing surface, ensuring a consistent, bubble-tight shut-off without the need for lubrication. This non-lubricated construction isolates the process media from the valve body for superior corrosion resistance, delivering reliable, contaminant-free operation and long-term integrity.
