PRESSURE SEAL BONNET GLOBE VALVE - CLASS 900
Product standards & features
| Standards | Detail |
| Design | API600 / BS 1873 |
| Face to Face | ANSI B16.10 |
| Flange Ends | ANSI B16.5 / B16.47 RF |
| Weld Ends | ASME B16.25 |
| Inspecion & Testing | API 598 |
| Marking | MSS SP-25 |
| Application | Coal industry, Oil&Gas, Power plant, Chemical industry, Waste water, water treatment industry |
| Features | Straight-body design for smooth flow OS&Y type with exposed stem for easy monitoring Bolted bonnet with integrated yoke for added strength Rising stem with handwheel operation Loose disc design – plug or ball option Replaceable seat ring for easy maintenance Impact handwheel standard from 10” up Optimized for horizontal installation Flanged or butt-welded ends available Optional gearbox for effortless control |
| Class | 900LB – 2500LB |
| Size | 2″ – 12” (DN50~DN300mm) |
| Material | Carbon steel (WCB) Alloy Steel (WC6 / WC9) Stainless steel (CF8 / CF8M) |
| Application Medium | water, oil, gas, corrosive |
| Application Temperature | -29℃~+425℃ (higher temperature is available upon request) |
PRODUCT DETAILS
PRESSURE SEAL BONNET GLOBE VALVE - CLASS 900
Charlies Valve’s Class 900-2500 Pressure Seal Bonnet Globe Valve is engineered for the most demanding high-pressure, high-temperature throttling applications. Its advanced pressure seal design leverages line pressure to forge a stronger, tighter body-bonnet seal as pressure increases. This ensures maximum joint integrity and dependable, leak-free control, providing the ultimate safety and precision required in critical power and process systems.
Product Downloads
Your direct source for Charlies Valve technical specifications and product catalogs.
